Tube & Pipe Fittings

Tubeplus specializes in high-quality tube and pipe fittings, designed for secure and leak-free connections in various industrial applications. These fittings are available in multiple configurations, including elbows, tees, reducers, couplings, and adapters, ensuring compatibility with diverse piping systems. Manufactured with precision, they meet industry standards for durability, corrosion resistance, and high-pressure performance.

Tubeplus fittings provide a reliable solution for efficient fluid and gas transfer, supporting applications in oil & gas, petrochemical, construction, and manufacturing industries. Their versatility and robustness make them ideal for both standard and high-demand environments, ensuring long-term operational efficiency in critical systems.

Specifications Of Tube & Pipe Fittings

Standard

API (American Petroleum Institute): API 5CT, API 6A, API 16A
ASTM (American Society for Testing and Materials): ASTM A182, ASTM A403, ASTM A234
ANSI (American National Standards Institute): ANSI B16.5, ANSI B16.9, ANSI B16.11
ISO (International Organization for Standardization): ISO 15156/NACE MR0175 (for sour service applications)
ASME (American Society of Mechanical Engineers): ASME B16.5, ASME B16.9, ASME B16.11

…

Materials

Stainless Steel: 304, 304L, 316, 316L, 321, 347
Carbon Steel: ASTM A105, A106, A234 WPB
Alloy Steel: ASTM A182 F5, F9, F11, F22, F91
Nickel Alloys: Inconel 625, Inconel 825, Monel 400, Hastelloy C276
Duplex & Super Duplex Stainless Steel: S31803, S32750, S32760
Copper & Brass: C12200, C70600, C71500 (for specialized applications)

…

Specifications

Sizes:
Tube Fittings: 1/8” to 2” (OD)
Pipe Fittings: 1/2” to 48” (Nominal Pipe Size)

Pressure Ratings:
Up to 10,000 psi for high-pressure applications
Standard ratings: 150#, 300#, 600#, 900#, 1500#, 2500# (ANSI Class)

Temperature Range:
Cryogenic (-196°C) to High-Temperature Service (up to 650°C)

Types:
Tube Fittings: Compression fittings, Ferrule fittings, Flare fittings
Pipe Fittings: Elbows, Tees, Couplings, Unions, Crosses, Reducers, Caps, Plugs
Threaded & Welded Fittings: NPT, BSP, Socket Weld, Butt Weld

Coatings & Treatments:
Anti-corrosion coatings: Zinc-plated, Epoxy-coated, PTFE-coated
Surface Finish: Pickling & passivation, Electro-polished

…
