Hybrid TEC Cable

Features

• Integrated Power & Data Transmission– Combines electrical conductors and fiber optics in a single metal-encapsulated cable, ensuring reliable power delivery and real-time data communication in downhole and harsh environments.
• 360° Mechanical Protection– Encased in stainless steel, Inconel, or Monel tubing, providing high resistance to pressure, corrosion, and mechanical stress.
• High-Temperature & High-Pressure Performance– Designed to withstand extreme operational conditions, with temperature ratings up to 300°C and pressure resistance exceeding 25,000 psi.
• Optimized for Downhole Sensing & Power Applications– Ideal for ESP (Electrical Submersible Pump) systems, permanent monitoring, and intelligent well completions, ensuring stable operation in deep wells.
• One-Piece Seamless Construction– Reduces the risk of leakage and mechanical failure, ensuring long-term performance and durability.
• Meets Industry Standards– Manufactured according to API, ASTM, and IEC 60794 standards for oil & gas, geothermal, and subsea applications.

Options

• Conductor Types:Copper, Nickel-plated Copper, or Alloy-based conductors for high-efficiency power transmission.
• Fiber Optic Options:Single-mode or multi-mode optical fibers for DTS, DAS, and real-time monitoring.
• Tube Materials:Stainless Steel (316L, 825), Inconel, Monel, or Titanium for enhanced environmental resistance.
• Customizable Sizes & Configurations:Available in various OD and wall thickness options to meet specific operational needs.
• High-Integrity Jacketed or Bare Hybrid TEC Configurationsfor added protection and flexibility.
• Compatible with All Standard Connectors & Splicing Technologiesfor seamless system integration.

The Hybrid TEC Cable offers a highly reliable, all-in-one solution for downhole, subsea, and industrial applications, enabling power transmission and fiber optic sensing in extreme conditions.
