FIMT & TEC Cable

Our FIMT (Fiber in Metal Tube) & TEC (Tubing Encapsulated Conductor) Cable are engineered for superior performance in extreme environments. FIMT cables provide robust fiber optic protection for reliable data transmission in high-temperature, high-pressure, and corrosive conditions. TEC cables, designed for downhole and subsea applications, ensure stable electrical signal transmission while withstanding mechanical stress. Both solutions can be customized to meet specific operational requirements, delivering durability and efficiency in critical industrial applications.

Specifications Of FIMT & TEC Cable

Standard

ASTM A269 / A632 (Stainless Steel Tubing)
IEC 60794 (Fiber Optic Cables)
API 19TT (Downhole TEC Cable)
ISO 13628-5 (Subsea Umbilical Cables)

…

Materials

FIMT: Stainless Steel (304, 316L), Inconel, Monel, Nickel Alloy
TEC Cable: Copper, Nickel-plated Copper, Stainless Steel, Inconel Sheath
Insulation: PEEK, ETFE, Polyimide
Jacket (if applicable): HDPE, FEP

…

Specifications

FIMT (Fiber in Metal Tube)

Fiber Type: Single-mode / Multi-mode
Tube OD: 1.0mm – 5.0mm
Wall Thickness: 0.15mm – 0.5mm
Temperature Rating: -200°C to +400°C
Pressure Rating: Up to 30,000 psi

TEC (Tubing Encapsulated Conductor) Cable

Conductor: 16AWG – 4AWG (Copper/Nickel-plated Copper)
Tube OD: 1/8” – 5/8”
Wall Thickness: 0.028” – 0.065”
Insulation: High-temp PEEK, ETFE, or Polyimide
Working Temperature: Up to +300°C
Pressure Rating: Up to 25,000 psi

…
